50ltr Heat Pump Buffer Tanks – A class rated
Specifically designed for use with Heat Pump installations to provide a stored volume of heated water which helps to prevent heat pump short cycling and can increase response times, COP and increase the life span of the heat pump. Use for treated water only.
The ACF-P range features wall mounting brackets featuring twin insulation layer and a rigid PVC Jacket. The ACF-P has an industry leading Class A energy rating and is ERP ready.
Product Code: ACF-50PLUS
Description: 50ltr heat pump buffer vessel – No Element
Dimensions: 410mm O/D x 880mm H
Specifications:
- Class A rated
- Wall Hung with welded fixing bracket
- Carbon steel
- Max pressure 10bar
- Min temperature -10°c
- Max temperature +95°c
Connections:
- 6 x 1-1/4” F side connections to suit flow and return from system and flow and return from Heat Pump (4 on one side, 2 on the other)
- 3 x 1/2” F sensor / monitoring ports
- 1 x 1-1/4” F top connection for air release valve
- 1 x 1-1/2” F immersion heater element port
- 1 x 1/2″ F lower side drain port
5 year warranty
